Airtac HD4V Solenoid Valve HD4V120FI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120FI High-Performance 5/2-Way Solenoid Valve
- Model: HD4V120FI
- Type: 5/2-way single solenoid (monostable) with manual override
- Port size: G1/2 (ISO 228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 L/min (Cv=1.5) at 0.5 MPa
- Response time: ≤25ms (exhaust to actuation)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE piston ring
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 1.3 kg (2.87 lbs)
- Dimensions: 140mm(L) × 55mm(W) × 100mm(H)
- Port thread depth: 12mm (minimum engagement)
- Power consumption: 2.2W (DC), 3.5VA (AC)
Industrial-grade directional control valve featuring optimized flow paths for high-speed cycling (up to 5Hz). The aluminum alloy body with hard anodized coating resists chemical corrosion and particulate wear. Designed for ISO 1 pneumatic systems, it integrates a manual override lever for emergency operation and system debugging.
- Automated assembly line clamping/unclamping systems
- Plastic injection molding machine ejectors
- CNC tool changers requiring rapid cylinder reversal
- Bottle blowing machine air distribution
- Automotive brake testing equipment
Installation guidelines:
Mount with 10-15mm clearance around exhaust ports for heat dissipation.
Use 40μm filtration with automatic drain. Lubricated air (ISO VG32)
recommended for extended service intervals (20 million cycles MTBF).
Critical note:
Avoid continuous energization >60 seconds to prevent coil overheating.
For vertical mounting, position electrical connector upward to prevent
condensation ingress.
| Property | Property Value |
|---|---|
| sku | HD4V120FI |
| Standard Voltage | DC12V |
