Airtac HD4V Solenoid Valve HD4V130CA
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V130CA Solenoid Valve Technical Specifications
- Model: HD4V130CA
- Type: 4V230-series 5/2-way double solenoid operated
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: BSPP (parallel thread)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max operating frequency: 5 Hz
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 1.15 kg ±2%
- Dimensions: 130mm(L) × 60mm(W) × 57mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -5℃ to 80℃ (with no freezing condensation)
- Power consumption: 3.8W (DC24V), 4.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Response time: ≤30ms (excitation), ≤20ms (de-excitation)
- Port configuration: 5 ports (P, A, B, EA, EB) / 2 positions
High-flow directional control valve with dual manual override and position indicator. Features corrosion-resistant aluminum alloy body with hard anodized treatment. Optimized spool design achieves 25% faster response than previous generation models. Requires ISO 8573-1:2010 Class 3.4.2 compressed air quality (max 5μm particles, -20℃ pressure dew point).
- Pneumatic cylinder sequencing in automotive assembly lines
- Clamping control for CNC machining centers
- Material handling systems with double-acting actuators
- Plastic injection molding machine valve gates
- Food processing equipment requiring frequent directional changes
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (max torque 2.5N·m).
Maintain minimum 30mm clearance below valve for exhaust port maintenance.
Use flexible tubing for first 500mm of connections to prevent vibration transfer.
| Property | Property Value |
|---|---|
| sku | HD4V130CA |
| Standard Voltage | AC220V |
