Airtac HD4V Solenoid Valve HD4V130CB
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V130CB High-Performance Solenoid Valve Technical Details
- Model: HD4V130CB
- Valve type: 5/3-way double solenoid (closed center)
- Port configuration: 1/4" BSPP (G1/4) female threads
- Effective section area: 17.5mm²
- Operating pressure range: 0.1-1.0 MPa (14.5-145 PSI)
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 3.8W (DC), 5.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Ambient temperature: -10℃ to 60℃ (with anti-freeze measures below 0℃)
- Fluid temperature: 5℃ to 60℃
- Protection rating: IP67 (dustproof/water immersion resistant)
- Body material: Anodized aluminum alloy (valve), PBT resin (coil)
- Weight: 850g ±5% (with coil)
- Dimensions: 126mm(L) × 54mm(W) × 65mm(H)
- Port positions: 5 ports (P, A, B, EA, EB) + 3 exhausts
Industrial-grade mid-size solenoid valve optimized for high-cycle automation systems. Features zero-pressure differential start capability and reinforced anti-vibration design with stainless steel internal components. Includes manual override button and LED operation indicator. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Plastic injection molding machine clamp controls
- Automated assembly line cylinder sequencing
- CNC machine tool pneumatic braking systems
- Beverage filling station actuator control
- Lithium battery production equipment
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use flexible tubing connections to absorb vibration. Lubricate with ISO VG32
turbine oil if operating below -5℃. Perform monthly exhaust port cleaning
in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | HD4V130CB |
| Standard Voltage | DC24V |
