Airtac HD4V Solenoid Valve HD4V130CBI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V130CBI High-Flow Solenoid Valve Technical Details
- Model: HD4V130CBI
- Type: 4V330C series 5-port/3-position closed center (Double solenoid)
- Port size: G1/4 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 4.0 (Kv=4.4)
- Response time: ≤25ms (at rated voltage)
- Weight: 680g ±2% (without connector)
- Dimensions: 121mm(L) × 57mm(W) × 75mm(H) (excluding fittings)
- Seal material: FKM (Fluorocarbon Rubber) standard, NBR optional
- Temperature range: -5℃ to 80℃ (with FKM seals)
- Power consumption: 4.5W (AC), 5.5W (DC)
- Protection rating: IP67 (Dustproof and waterproof)
- Porting pattern: ISO 5599-1 standard
- Manual override: Built-in emergency switch
High-performance pneumatic directional control valve featuring dual-coil operation with position memory function. Engineered for heavy-duty industrial applications with reinforced brass body and anti-vibration design. Includes LED status indicator and surge protection circuitry. Requires ISO 8573-1:2010 Class 3 compressed air (max 50μm particle size).
- Plastic injection molding machine clamping systems
- Automated assembly line cylinder control
- CNC machine tool chuck actuators
- Material handling systems (stackers/palletizers)
- Automotive production line robotics
- Food processing equipment (with optional stainless steel version)
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (not included).
Maintain minimum 20mm clearance above valve for heat dissipation.
Use locknuts with 25-30N·m torque for port connections. Lubricate with ISO VG32 turbine oil if used in dry air systems.
| Property | Property Value |
|---|---|
| sku | HD4V130CBI |
| Standard Voltage | DC24V |
