Airtac HD4V Solenoid Valve HD4V130CC
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V130CC Solenoid Valve Technical Specifications
- Model: HD4V130CC
- Type: 5/3-way double solenoid operated (Closed center)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (excluding connectors)
- Dimensions: 120mm(L) × 55mm(W) × 72mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Temperature range: -20℃ to 80℃ (non-freezing)
- Flow coefficient (Cv): 2.3 (at 0.5 MPa)
- Response time: ≤25ms (excitation), ≤35ms (de-excitation)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
The HD4V130CC features triple-position control with precision pilot-operated design, optimized for high-cycle industrial applications. Its stainless steel armature and anti-vibration structure ensure 10 million+ cycles durability. The valve body uses anodized aluminum alloy with integrated surge protection diodes. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (40μm filtration recommended).
- Automated assembly line clamping systems
- Plastic injection molding machine sequence control
- Food-grade pneumatic actuators (NSF compliant version available)
- Semiconductor wafer handling robotics
- Hydraulic system pilot stage control
Installation protocol:
Mount with vibration-damping brackets in any orientation (vertical preferred).
Maintain 15mm clearance for heat dissipation. Lubricate using ISO VG32 turbine oil
if air line lubrication isn't present. Perform manual override test monthly.
| Property | Property Value |
|---|---|
| sku | HD4V130CC |
| Standard Voltage | AC 110V |
