Airtac HD4V Solenoid Valve HD4V130CCI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V130CCI Solenoid Valve Technical Details
- Model: HD4V130CCI
- Type: 4V series 5-port 2-position (4V210-XX)
- Port configuration: 5/2-way (dual solenoid)
- Port size: PT1/2 (G1/2 equivalent)
- Effective area: 130mm² (critical flow path dimension)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Power consumption: 4.5W (AC), 3.6W (DC)
- Response time: ≤20ms (at rated pressure)
- Weight: 1.25kg (including coil and connector)
- Dimensions: 136mm(L) × 53mm(W) × 58mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal compatibility: NBR (standard), optional FKM/Viton®
- Ambient temperature: -5℃ to 60℃ (with condensation prevention)
- Protection class: IP67 (dustproof/water immersion resistant)
- Manual override: Built-in emergency push button
High-flow directional control valve with dual solenoid operation, featuring integrated silencer and shock-absorbing mechanism. Optimized spleeve structure ensures ≤0.5L/min internal leakage at max pressure. Requires 5μm filtration (40μm for basic applications). Compatible with ISO 15407-1 standards.
- Plastic injection molding machine cylinder control
- Automated assembly line actuator sequencing
- Textile machinery tension control systems
- Die-casting equipment pneumatic circuits
- Palletizing robot end-effector operations
Installation protocol:
Mount horizontally with manifold alignment pins. Allow 20mm service
clearance for manual override access. Use thread sealant on port
connections (PTFE tape prohibited). Perform monthly plunger rod
lubrication with ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | HD4V130CCI |
| Standard Voltage | AC 110V |
