Airtac HFK Guided Parallel Type Pneumatic Gripper HFK16
$144.66
Regular price
$152.16
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFK16
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Multiple bore sizes, specifications, and jaw type configurations available
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
Operation tip:
For precision gripping of delicate items, maintain 0.3-0.5MPa operating pressure and install
a 5-10μm filter regulator. Lubricate guide rails monthly with ISO VG32 turbine oil.
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK16 Guided Parallel Pneumatic Gripper Technical Details
- Model: HFK16
- Type: Double-acting guided parallel gripper
- Gripping force: 50-180N (adjustable via pressure)
- Stroke per jaw: 0-6mm (standard), customizable up to 15mm
- Operating pressure: 0.1-0.7 MPa
- Guide mechanism: Dual linear ball bearing slides
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (dual ports for simultaneous actuation)
- Body material: Anodized aluminum alloy (A6063)
- Slide rails: Stainless steel (SUS440C) with chrome plating
- Seals: NBR standard (FKM/Viton optional)
- Temperature range: -10℃ to 80℃ (NBR) / -20℃ to 150℃ (FKM)
- Protection class: IP54 (standard), IP67 with optional wipers
- Air consumption: 3.2cm³/stroke at 0.5MPa
- Speed control: Built-in adjustable cushioning mechanism
- Mounting: 4x M4 threaded holes (bottom/top/side mounting)
- Weight: 340g ±5% (without accessories)
- Dimensions: 76mm(L) × 34mm(W) × 42mm(H)
Precision-engineered parallel gripper with dual hardened steel guide rails for ultra-stable linear motion. Features anti-rotation design for maintaining jaw parallelism within 0.05mm throughout full stroke. Optimized for high-cycle applications with 10 million+ cycle durability under proper maintenance.
Industrial Applications:
- PCB component insertion machines
- Automotive fuel injector assembly
- Pharmaceutical blister packaging
- Watch movement part handling
- Optical lens positioning systems
Operation tip:
For precision gripping of delicate items, maintain 0.3-0.5MPa operating pressure and install
a 5-10μm filter regulator. Lubricate guide rails monthly with ISO VG32 turbine oil.
Configuration options:
- Custom jaw face patterns (V-groove, rubber pads, vacuum adapters)
- Magnetic sensor ready (2mm slot for inductive proximity switches)
- High-temperature variant available (150℃ continuous operation)
| Property | Property Value |
|---|---|
| sku | HFK16 |
| Gripper Optional Types | Standard Type |
| Opening/Closing Stroke | <6mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
