Airtac HFK Guided Parallel Type Pneumatic Gripper HFK25N
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK25N Guided Parallel Pneumatic Gripper Specifications
- Model: HFK25N
- Type: Guided parallel gripper (double rail)
- Bore size: Φ25mm
- Operating pressure: 0.1–0.7 MPa
- Stroke per jaw: 0–12mm (adjustable)
- Max gripping force: 180N @0.5MPa
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8
- Rail type: Dual hardened steel guide rods
- Repeat accuracy: ±0.02mm
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Buffer type: Elastic cushioning
- Mounting options: Through holes (4xM4) + alignment pins
- Weight: 0.82kg
- Dimensions: 146mm(L) × 48mm(W) × 40mm(H)
Precision parallel gripper with dual linear guide rails for ultra-stable linear motion. Features zero-backlash design and adjustable stroke limiter for delicate object handling. Optimized for high-cycle applications with wear-resistant PTFE-coated guide rods. Requires ISO 8573-1:2010 Class 3 compressed air.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Micro-motor shaft handling
- Optical lens assembly stations
- Watch component sorting systems
Installation tip:
Apply lithium soap-based grease to guide rails every 50,000 cycles.
Use counterbalance valves when handling vertically suspended loads.
- Precisely align guide rails with mounting surface using alignment pins
- Adjust stroke limit screws with 1.5mm hex key (0.05mm/rotation)
- Install shock absorbers for payloads over 0.5kg
- Maintain 0.3-0.5MPa for fragile objects (glass/ceramics)
| Property | Property Value |
|---|---|
| sku | HFK25N |
| Gripper Optional Types | Through-hole mounting type |
| Opening/Closing Stroke | 14mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
