Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL10
The HFKL series from AIRTAC represents a parallel-type guided pneumatic gripper engineered for high-precision operations. Available in standardized bore sizes (16mm, 20mm, 25mm, 32mm, and 40mm), this rail-guided design ensures exceptional alignment stability and repeatable gripping accuracy across automated processes. As a human-hand replacement solution, it significantly enhances production efficiency while maintaining operational safety in pick-and-place, assembly, and material handling applications.
Key features include integrated linear guide rails for reduced deflection, optimized gripping force transmission, and compatibility with various jaw configurations. The HFKL series exemplifies AIRTAC's commitment to delivering industrial-grade pneumatic gripping solutions with enhanced durability and maintenance efficiency. Category: Parallel Pneumatic Grippers | Brand: AIRTAC | Series: HFKL
AirTAC HFKL10 Guided Parallel Pneumatic Gripper Specifications
- Model: HFKL10
- Type: Guided parallel gripper (dual-piston design)
- Gripping force: 50N max @ 0.8MPa
- Stroke per jaw: 10mm
- Operating pressure: 0.1–0.7 MPa
- Port size: M5 × 0.8 (dual ports for push/pull action)
- Guide mechanism: Precision linear ball bearings
- Weight: 0.65kg (including rails)
- Dimensions: 105mm(L) × 50mm(W) × 40mm(H)
- Body material: Anodized aluminum alloy
- Rail material: Hardened stainless steel
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Repeatability: ±0.02mm
- Protection rating: IP54
High-precision parallel gripper with integrated linear guides ensuring zero rotational deviation during operation. Features dual opposing cylinders for balanced force distribution and hardened steel rails for wear resistance. Optimized for 2,000,000+ cycle durability with self-lubricating guide bushings. Requires 5μm filtered air.
- PCB handling in electronics assembly lines
- Precision lens positioning in optical manufacturing
- Medical device component insertion
- Automated packaging of small cosmetic items
- Robotic pick-and-place for watch components
Mounting tip:
Use M4×8mm socket head screws (recommended torque 1.2N·m) on both ends of the rail block.
Lubricate guide shafts with ISO VG32 hydraulic oil every 500km of travel.
| Property | Property Value |
|---|---|
| sku | HFKL10 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <8mm> |
