Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL10B
The HFKL series from AIRTAC represents a parallel-type guided pneumatic gripper engineered for high-precision operations. Available in standardized bore sizes (16mm, 20mm, 25mm, 32mm, and 40mm), this rail-guided design ensures exceptional alignment stability and repeatable gripping accuracy across automated processes. As a human-hand replacement solution, it significantly enhances production efficiency while maintaining operational safety in pick-and-place, assembly, and material handling applications.
Key features include integrated linear guide rails for reduced deflection, optimized gripping force transmission, and compatibility with various jaw configurations. The HFKL series exemplifies AIRTAC's commitment to delivering industrial-grade pneumatic gripping solutions with enhanced durability and maintenance efficiency. Category: Parallel Pneumatic Grippers | Brand: AIRTAC | Series: HFKL
AirTAC HFKL10B Guided Parallel Pneumatic Gripper Specifications
- Model: HFKL10B (Guided Parallel Type)
- Bore size: Φ10mm
- Stroke: 5mm (Standard)
- Operating pressure: 0.05-0.7 MPa
- Gripping force: 3.9N @0.5MPa (Per Finger)
- Drive method: Double-acting
- Guide type: Dual linear ball bearing rails
- Repeat accuracy: ±0.02mm
- Port size: M5×0.8 (Dual ports)
- Material: Aluminum alloy body, hardened steel guide rails
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 0.25kg (Without accessories)
- Dimensions: 90mm(L) × 30mm(W) × 24mm(H)
- Mounting pattern: 20mm spaced M3 threaded holes
- Max sliding friction: 0.3N
- IP rating: IP54 (Standard)
Precision parallel gripper with integrated linear guides, delivering exceptional positional accuracy and smooth motion characteristics. The hardened steel rails provide 5μm surface roughness for low-friction operation, while the dual-bearing design ensures zero rotational play during gripping operations. Features symmetrical air ports for flexible piping arrangements.
- PCB component insertion machines
- Micro-precision assembly in watch manufacturing
- Pharmaceutical blister packaging systems
- Optical lens handling in camera modules
- Small robotic end-effectors (≤3kg payload)
- Laboratory automation sample handling
Operational guidance:
For maximum precision, maintain air supply filtration at 5μm or finer.
Apply silicone-free lubricant every 500,000 cycles. Avoid side-loading
forces exceeding 2N. Alignment shims recommended when mounting
to 6-axis robots.
| Property | Property Value |
|---|---|
| sku | HFKL10B |
| Gripper Optional Types | Side-mounted |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <8mm> |
