Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK16
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK16 Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK16
- Type: Guided parallel gripper (double-acting)
- Bore size: Φ16mm
- Gripping force: 42N@0.5MPa / 67N@0.7MPa
- Stroke per jaw: 0-12mm (adjustable)
- Operating pressure: 0.2-0.7 MPa
- Guide mechanism: Dual linear ball bearings
- Port size: M5x0.8 (standard), NPT1/8 optional
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54
- Weight: 480g ±5%
- Dimensions: 115mm(L) × 42mm(W) × 32mm(H)
- Mounting: 4x M4 threaded holes (depth 8mm)
Precision-guided parallel gripper with dual linear ball bearing slides for smooth operation and minimal deflection. Features tool-free stroke adjustment via hex key and integrated T-slot for sensor mounting. Optimized for high-speed cycling (up to 3 cycles/sec) with shock-absorbing rubber bumpers. Requires filtered air (5-50μm) with lubricator or dry air operation.
- PCB handling in SMT assembly lines
- Automotive component transfer systems
- Pharmaceutical blister packaging
- Precision gearbox assembly
- Battery cell sorting robots
- Optical lens positioning devices
Maintenance note:
Relubricate guide rails every 500,000 cycles using ISO VG32 turbine oil.
Avoid side loads exceeding 15N to prevent bearing wear. For vacuum environments,
use optional vacuum-rated seals (FKM material).
| Property | Property Value |
|---|---|
| sku | HFSK16 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
