Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK16W
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK16W Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK16W
- Type: Guided parallel gripper with linear slide rails
- Bore size: Ø16mm
- Operating pressure: 0.05-0.7 MPa
- Gripping force: 16N (at 0.5MPa)
- Stroke per finger: 0-9mm
- Repeat accuracy: ±0.02mm
- Max speed: 150mm/s
- Weight: 0.42kg
- Dimensions: 108mm(L) × 42mm(W) × 28mm(H)
- Mounting pattern: 30mm × 18mm (2×M4 threaded holes)
- Slide rail type: Dual hardened steel guide rods
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Air connection: M5 × 0.8 (2 ports)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km travel)
Precision parallel gripper featuring dual hardened guide rails for ultra-stable linear motion. The HFSK16W combines high rigidity with low inertia, delivering precise centering grip force through its patented wedge mechanism. Anti-vibration design minimizes positional drift during high-speed operation.
- PCB component insertion machines
- Precision gear assembly systems
- Medical device micro-part handling
- Automotive fuel injector production lines
- Semiconductor wafer cassette transfer
Operation note:
For optimal performance, maintain air supply dew point 15℃ below ambient temperature.
Use 5-30μm filtration and install speed controllers to prevent impact damage at full stroke ends.
- Vertical or horizontal installation supported
- Maximum side load capacity: 25N
- Recommended mounting torque: 3.5N·m (M4 screws)
- Alignment tolerance: ±0.1mm between mating surfaces
| Property | Property Value |
|---|---|
| sku | HFSK16W |
| Gripper Optional Types | Side mount, narrow claw type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
