Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK20W
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK20W Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK20W
- Type: Parallel guided gripper with integrated rail
- Gripping force: 20N @ 0.5MPa
- Stroke per jaw: 20mm
- Operating pressure: 0.1-0.7 MPa
- Port size: M5 (1/8")
- Weight: 0.45kg (bare gripper), 0.68kg (with accessories)
- Dimensions: 100mm(L) × 40mm(W) × 40mm(H)
- Material: Aluminum alloy body, NBR seals
- Temperature range: -10℃ to 80℃
- Repeat accuracy: ±0.02mm
- Guide mechanism: Dual slide rail system
- Response time: 0.3s (full stroke at 0.5MPa)
- Mounting pattern: ISO 9409-1-50-4-M6
- Protection rating: IP54
High-precision parallel gripper featuring wear-resistant guide rails and optimized air chamber design for smooth operation. The T-slot mounting surface allows flexible sensor/stopper integration. Precision ground guide surfaces achieve <5μm surface roughness for consistent repeatability. Requires 5μm filtered compressed air.
- PCB component insertion machines
- Pharmaceutical blister packaging
- Precision bearing handling systems
- Automotive fuel injector assembly
- Food-grade packaging (FDA-compliant versions available)
Operation tip:
For delicate object handling, install adjustable shock absorbers (ASNU-6 model recommended)
and maintain 0.3-0.5MPa working pressure. Lubricate guide rails every 500,000 cycles using
ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | HFSK20W |
| Gripper Optional Types | Side mount, narrow claw type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
