Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK25
$203.29
Regular price
$210.79
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFSK25
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Multiple bore sizes and specifications available, with diversified gripper types for selection.
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
Installation notes:
Apply lithium-based grease to rails every 500,000 cycles. Use M4×16mm SHCS
(socket head cap screws) with 0.6-0.8Nm torque for mounting. Maintain 0.5mm
clearance between jaw tips and workpiece during initial calibration.
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK25 Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK25
- Type: Rail-guided parallel movement (twin-piston design)
- Bore size: Φ25mm
- Operating pressure: 0.2–0.7 MPa
- Max gripping force: 180N @0.5MPa
- Stroke per jaw: 8mm (standard), customizable up to 15mm
- Weight: 520g ±5% (including rail and accessories)
- Dimensions: 118mm(L) × 50mm(W) × 36mm(H)
- Rail length: 92mm (integrated mounting surface)
- Mounting holes: 4×M4 threaded (8mm pitch)
- Material: Anodized aluminum body, hardened steel guide rails
- Seals: NBR/PU options (temperature-resistant up to 80℃)
- Air consumption: 9.5cm³ per stroke
- Repeat accuracy: ±0.05mm
- Response time: 50ms @0.5MPa
- Protection rating: IP54 (standard), IP67 optional
Precision parallel gripper with integrated linear guides for stable centering motion. Features zero-backlash operation through dual piston drive and adjustable clamping force via pressure regulation. The hardened rail system ensures 50km+ service life under full load. Compatible with ISO 9400-1 mounting interfaces.
Typical Applications:
- High-speed pick-and-place systems (2,400 cycles/hour)
- PCB handling in electronics assembly lines
- Precision component insertion in automotive manufacturing
- Medical device packaging with cleanroom compatibility
- Glass panel transfer systems with vacuum tool integration
Installation notes:
Apply lithium-based grease to rails every 500,000 cycles. Use M4×16mm SHCS
(socket head cap screws) with 0.6-0.8Nm torque for mounting. Maintain 0.5mm
clearance between jaw tips and workpiece during initial calibration.
Optional Accessories:
- HSK-25T: Tool changer adapter plate
- PGK-25: Polyurethane finger pads (non-marring)
- MSQ-25: Magnetic sensor kit for position feedback
- CL-25F: Filter-regulator lubricator combo unit
| Property | Property Value |
|---|---|
| sku | HFSK25 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
