Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ16
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ16 Guided Parallel Pneumatic Gripper Specifications
- Model: HFSZ16
- Type: Guided parallel gripper with linear slide mechanism
- Bore size: Ø16mm
- Operating pressure: 0.2–0.7 MPa
- Max gripping force: 120N (at 0.5MPa)
- Stroke per finger: 0–12mm (adjustable)
- Repeat accuracy: ±0.03mm
- Port size: M5×0.8 (dual ports for push/pull action)
- Slide rail type: Dual linear guideways with ball bearings
- Body material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Weight: 420g ±5g
- Dimensions: 105mm(L) × 42mm(W) × 32mm(H)
- Mounting: 4×M4 threaded holes (front/rear mounting options)
- Shock resistance: 15m/s² max
- Protection rating: IP54 (standard), IP67 optional
Precision-engineered parallel gripper featuring dual hardened steel guide rails for exceptional alignment stability during high-speed operations. The tapered jaw interface design allows quick tooling changes, while the self-lubricating bushings ensure maintenance-free operation. Compatible with ISO 9409-1 mounting patterns for robotic integration.
- CNC machine tool part loading/unloading
- Electronics component insertion systems
- Pharmaceutical blister packaging lines
- Precision bearing assembly stations
- 3C industry automated testing equipment
Operational note:
For optimal performance, maintain air supply dew point at least 5℃ below ambient temperature.
Use adjustable shock absorbers when cycle rate exceeds 2Hz. Lubricate guide rails with ISO VG32
turbine oil every 500,000 cycles in continuous operation.
| Property | Property Value |
|---|---|
| sku | HFSZ16 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
