Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ25
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ25 Guided Parallel Pneumatic Gripper Technical Details
- Model: HFSZ25
- Type: Guided parallel gripper (dual rail design)
- Bore size: Ø25mm
- Operation method: Double-acting
- Operating pressure: 0.1-0.7 MPa
- Max stroke: 10mm (adjustable in 2mm increments)
- Gripping force: 120N @0.5MPa
- Guide rail type: Precision ground hardened steel
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber bumper
- Speed range: 50-800mm/s
- Mounting: 4x M4 threaded holes (side/flange)
- Weight: 1.8kg ±5%
- Dimensions: 180mm(L) × 105mm(W) × 58mm(H)
Industrial-grade parallel gripper featuring dual hardened guide rails for precision alignment, designed for high-cycle automation applications. The T-slot rail system enables smooth linear motion with anti-torsion stability. Includes wear-compensation mechanism and IP54-rated construction against particulate ingress.
- CNC machine tool part handling
- Robotic assembly of precision components
- PCB panel transfer systems
- Automotive component sorting
- Pharmaceutical blister pack handling
Operation note:
Lubricate guide rails with ISO VG32 hydraulic oil monthly.
Use 40μm filtered dry air with 1-3 drops of ISO VG32 oil per m³.
Max lateral offset load: 15N.
| Property | Property Value |
|---|---|
| sku | HFSZ25 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
