Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK10
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK10 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK10
- Type: Guided parallel gripper (dual rail design)
- Gripping force: 30N @ 0.5MPa
- Stroke per jaw: 5mm (adjustable via mechanical stops)
- Operating pressure: 0.1–0.7 MPa
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Rail type: Hard-anodized aluminum with self-lubricating bushings
- Repeat accuracy: ±0.02mm
- Material: Aluminum alloy body, hardened steel guide rails
- Temperature range: -10℃ to 80℃
- Protection rating: IP40
- Weight: 320g ±5g
- Dimensions: 60mm(L) × 40mm(W) × 35mm(H)
- Mounting pattern: 25mm interaxis hole spacing (ISO 9409-1 compatible)
- Actuation: Double-acting (requires 4 ports)
- Seal material: NBR (standard) / FKM (high-temp option)
- Shock resistance: 15G acceleration (3ms duration)
Precision parallel gripper with integrated linear guides for smooth, wobble-free operation. Features adjustable mechanical stops and dual piston design for symmetrical force distribution. The hardened steel rails provide over 3,000km service life under standard loads. Compatible with vacuum suction cup adapters for hybrid gripping solutions.
- PCB handling in electronics assembly lines
- Precision part positioning in optical device manufacturing
- Carton flap folding in packaging machinery
- Medical device component assembly
- Battery cell transfer in EV production
- Semiconductor wafer handling (cleanroom compatible version available)
Installation tip:
Use precision alignment jigs during mounting to ensure parallel rail orientation.
For high-cycle applications (>1M cycles/year), apply light machine oil (ISO VG32)
to guide rails monthly. Avoid side-loading beyond 10N to prevent bushing wear.
- Optional magnetic sensor slots (M5 size) for position feedback
- Anti-corrosion coating available for food/pharma environments
- Custom jaw mounting patterns (submit DXF for OEM requests)
- High-speed variant (HFTK10-HS) with reduced mass for 3Hz operation
| Property | Property Value |
|---|---|
| sku | HFTK10 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
