Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK20B
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK20B Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK20B
- Type: Guided parallel gripper (dual rail structure)
- Gripping force: 20N @ 0.5MPa
- Bore size: Ø20mm cylinder
- Action type: Double-acting
- Operating pressure: 0.1–0.7 MPa
- Rail material: Aluminum alloy with hard anodized surface
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Repeatability: ±0.05mm
- Port size: M5x0.8 (1/8" NPT optional)
- Max stroke: 25mm
- Load capacity: 2.5kg (vertical), 5kg (horizontal)
- Mounting options: Side/vertical mounting with 4x M4 threaded holes
- Weight: 0.52kg (excluding accessories)
- Dimensions: 80mm(L) × 40mm(W) × 40mm(H)
- Protection rating: IP54
Precision-guided parallel gripper featuring hardened steel guide rails with linear ball bearings for smooth operation and zero rotational play. The dual piston design ensures symmetrical gripping force distribution, with integrated shock absorption at stroke ends. Compatible with vacuum cups/magnetic tools via T-slot mounting.
- PCB handling in SMT assembly lines
- Precision parts transfer in watch manufacturing
- Battery cell stacking in energy storage systems
- Medical device assembly requiring ISO Class 5 cleanliness
- Robotic pick-and-place in 3C industry automation
Operational guidance:
Lubricate guide rails with ISO VG32 hydraulic oil monthly.
Use 5-10μm filtered air with 1-3 drops of oil per m³.
Maximum lateral offset load: 1/3 of vertical capacity.
| Property | Property Value |
|---|---|
| sku | HFTK20B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
