Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK20F
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK20F Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK20F
- Type: Guided parallel gripper (double-acting)
- Gripping force: 40N max @ 0.6MPa
- Stroke per finger: 0-20mm
- Operating pressure: 0.15–0.7 MPa
- Guide mechanism: Dual linear ball bearings
- Repeat accuracy: ±0.02mm
- Port size: M5 (standard), NPT1/8 optional
- Operating temperature: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Protection rating: IP54
- Weight: ~650g (without accessories)
- Dimensions: 105mm(L) × 45mm(W) × 32mm(H)
- Mounting pattern: 4×M4 threaded holes (8mm spacing)
- Max operating speed: 500mm/s
- Lifespan: 5,000km travel distance (under rated load)
Precision-engineered parallel gripper with integrated linear guides, designed for high-speed pick-and-place operations requiring exceptional alignment stability. Features low-friction ball bearing guidance and symmetrical force distribution, ideal for delicate object handling. Compatible with ISO 9409-1 mounting interfaces.
- Robotic assembly line component insertion
- CNC machine tool part loading/unloading
- Pharmaceutical blister pack handling
- PCB board positioning systems
- Automotive sensor module assembly
- Food packaging end-effector tooling
Operation note:
For optimal performance, maintain air supply dew point below 3℃ and install
adjustable flow controls on both inlet ports. Lubricate guide rails every
5,000 cycles using ISO VG32 pneumatic oil.
- Optional magnetic sensor slots (M5x0.8 thread)
- Custom finger mounting patterns available
- High-temperature variant (up to 120℃) with FKM seals
- Anti-corrosion version for washdown environments
| Property | Property Value |
|---|---|
| sku | HFTK20F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
