Airtac HFTKL Guided Parallel Type Pneumatic Gripper HFTKL20
Type: Rail-Guided Parallel Pneumatic Gripper
Brand: AirTAC
Series: HFTKL
AirTAC HFTKL20 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTKL20
- Type: Guided parallel gripper (double-acting)
- Gripping force: 70N @0.4MPa / 105N @0.6MPa
- Stroke per jaw: 0-20mm (adjustable)
- Operating pressure: 0.2-0.7 MPa
- Guide rail type: Dual linear ball bearings
- Repeat accuracy: ±0.02mm
- Port size: M5 (1/8")
- Body material: Anodized aluminum alloy
- Rail material: Carbon steel with chrome plating
- Temperature range: -10℃ to 80℃
- Weight: 1.65kg
- Dimensions: 153mm(L) × 60mm(W) × 42mm(H)
- Protection rating: IP54 (standard)
- Lubrication: Pre-lubricated (Grease-free operation)
Precision-guided parallel gripper with synchronized jaw movement, featuring dual hardened steel rails for ultra-stable linear motion. Optimized for high-cycle applications requiring micron-level repeatability. Integrated T-slot mounting system allows multi-position installation. Compatible with ISO 9409-1 mounting interfaces.
- CNC machine tool loading/unloading systems
- Precision electronic component assembly
- Pharmaceutical blister packaging
- Automotive fuel injector handling
- 3C product testing equipment
- Silicon wafer transfer robots
Installation note:
Ensure rail alignment within 0.1mm/meter using precision level during mounting.
Apply lithium-based grease (Molykote EM-30L recommended) every 500km of travel
or 6 months in continuous operation.
| Property | Property Value |
|---|---|
| sku | HFTKL20 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | 18mm |
