Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ20
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ20 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ20
- Type: Guided parallel gripper (dual rail)
- Bore size: Ø20mm
- Operating pressure: 0.05-0.7 MPa
- Stroke options: 10/15/20/25/30/40/50mm (customizable)
- Gripping force: 18-250N (pressure-dependent)
- Repeat accuracy: ±0.05mm
- Rail type: Precision linear guideway
- Mounting options: Side/end mounting holes (M4×0.7)
- Port size: PT1/8 (G1/8 adaptor optional)
- Material: Aluminum alloy body, hardened steel guide rails
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Weight: 0.45kg (base model with 20mm stroke)
- Dimensions (L×W×H): 100mm × 40mm × 40mm (20mm stroke model)
- Max finger length: 100mm (recommended)
- Air consumption: 4.3cm³ per mm stroke
A high-precision guided gripper featuring dual linear rails for enhanced rigidity and anti-torsion capability. The hardened steel guide system ensures minimal play during operation (<0.03mm lateral deflection at full load). Optimized flow path design achieves 80ms open/close cycle time at 0.5MPa. Includes adjustable mechanical stoppers for stroke fine-tuning.
- PCB component insertion machines
- Automated optical inspection (AOI) systems
- Pharmaceutical blister packaging lines
- Robotic assembly of precision gears
- Semiconductor wafer handling
- Automotive fuel injector production
Installation notes:
- Apply lithium-based grease to guide rails monthly
- Maintain 0.3-0.5MPa air pressure for optimal lifespan
- Use counterbore mounting (depth 7mm±0.5) for vibration resistance
- Install shock absorbers when stroke >30mm
| Property | Property Value |
|---|---|
| sku | HFTZ20 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
