Airtac HFZ Parallel Type Pneumatic Gripper HFZ40B
2、Positioning pins on the guide base prevent misalignment between the rail and main body;
3、Deepened fixed reference centering holes on the body enhance mounting accuracy and ensure consistent repositioning during repeated disassembly/reassembly;
4、Customizable initial gripping positions cater to diverse operational conditions based on client-specific requirements.
Category: Parallel Grippers | Brand: Airtac | Series: HFZ
AirTAC HFZ40B Parallel Pneumatic Gripper Technical Details
- Model: HFZ40B (Parallel Clamping Type)
- Bore size: Ø40mm
- Action type: Double-acting
- Operating pressure: 0.1-0.7 MPa
- Stroke per jaw: 8mm (Standard), customizable 4-20mm
- Max gripping force: 215N @0.6MPa
- Port size: M5x0.8 (Standard), G1/8 optional
- Repeat accuracy: ±0.05mm
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃ (NBR seals)
- Weight: 680g ±2%
- Dimensions: 132mm(L) × 62mm(W) × 52mm(H)
- Rod thread: M6 internal (for jaw customization)
- Mounting: 4x M5 threaded holes (ISO 21287 compliant)
- Protection rating: IP54 (standard), IP67 with optional kit
High-precision parallel gripper featuring dual guided rods and anti-rotation mechanism for stable centering. Optimized for medium-duty applications requiring precise part alignment, with hardened steel guide shafts and wear-resistant bushings. Includes built-in air cushioning adjustment (5-stage) for shock absorption.
- CNC machine tool loading/unloading systems
- PCB component insertion machines
- Automotive engine part assembly lines
- Pharmaceutical blister packaging
- Robotic palletizing end-effectors
- 3C product testing equipment
Installation guidelines:
Use ISO VG32 hydraulic oil or equivalent for lubrication.
Avoid side load exceeding 30N during operation.
For vacuum applications, specify optional vacuum-compatible seals (FKM material).
- Jaw face options: V-groove, rubber pad, vacuum cup adapter
- Position sensors: M5/M8 inductive proximity switches
- Mounting brackets: ISO 9409-1-50-4-M6 pattern
| Property | Property Value |
|---|---|
| sku | HFZ40B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <40mm> |
| Stroke | 30mm |
