Airtac HGS Micro Precision Slide Table Cylinder HGS12X15
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS Miniature Precision Slide Cylinder HGS12X15 Specifications
- Model: HGS12X15
- Bore size: Ø12mm
- Stroke: 15mm (Standard strokes: 5-50mm available)
- Operating pressure: 0.05-0.7 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (Dual ports for forward/return)
- Cushioning: Adjustable rubber buffer (both ends)
- Piston speed: 50-700mm/s
- Repeat positioning accuracy: ±0.1mm
- Rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU hybrid seals
- Weight: 0.26kg (with mounting brackets)
- Dimensions: 80mm(L) × 22mm(W) × 19.5mm(H)
- Protection class: IP54 (Dust protected & water spray resistant)
- Lubrication: Pre-lubricated (Maintenance-free for 2000km travel)
Ultra-compact linear actuator with integrated slide guide mechanism, featuring dual-axis alignment for precision linear motion. The hardened steel guide rails and four-ball bearing design ensure smooth operation with ≤0.03mm wobble tolerance. Includes magnetic piston for position sensing compatibility (sensor not included).
- Micro-dispensing systems in semiconductor manufacturing
- Optical lens positioning stages
- PCB test probe actuation mechanisms
- 3D printer nozzle alignment systems
- Medical device assembly automation
- Robotic end-effector micro-adjustments
Installation guidelines:
Mount on flat surface with M3 screws (max torque 0.6N·m).
Use 5μm filtered dry air with ISO VG32 turbine oil mist lubrication (1 drop/500k cycles).
Avoid side-load forces exceeding 5N. For vertical mounting, install locking collar (accessory HGS-LK12).
| Property | Property Value |
|---|---|
| sku | HGS12X15 |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
