Airtac HGS Micro Precision Slide Table Cylinder HGS12X20J
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS Micro Precision Slide Cylinder HGS12X20J Technical Details
- Model Code Breakdown: HGS12X20J
- HGS: Micro precision slide cylinder series
- 12: 12mm bore diameter
- 20: 20mm stroke length
- J: Built-in slide guide mechanism
- Operating Pressure: 0.05-0.7 MPa (7-100 PSI)
- Ambient Temperature: -10℃ to 60℃ (14℉ to 140℉)
- Cushioning: Adjustable rubber buffer (both ends)
- Port Size: M5x0.8 (standard) with optional NPT1/8 adapter
- Piston Material: Hard anodized aluminum alloy
- Rod Material: Stainless steel SUS304
- Seal Type: Multi-lip seal with NBR compound
- Repeat Accuracy: ±0.02mm
- Max Speed: 500 mm/s
- Weight: 180g ±5g (without accessories)
- Dimensions:
- Length: 82mm (including mounting brackets)
- Body Width: 24mm
- Height: 32mm (guide rail surface to base)
Ultra-compact linear actuator combining pneumatic power with precision linear guidance, featuring dual-axis stabilization through integrated ball guide rails. The chromium-plated shaft and self-lubricating bushings enable smooth operation with ≤0.5N dynamic friction. Optional magnetic piston versions (add "-M" suffix) enable position feedback when paired with proximity sensors.
- PCB component insertion machines
- Optical lens alignment systems
- IVD medical analyzer reagent handling
- Semiconductor wafer cassette transfer
- High-speed sorting mechanisms (pharmaceuticals/electronics)
Installation protocol:
Requires periodic lubrication (every 50km travel) with ISO VG32 hydraulic oil.
Mounting surface flatness must be within 0.05mm/m. For vertical installations,
use model suffix "V" with upgraded seal kit.
| Property | Property Value |
|---|---|
| sku | HGS12X20J |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
