Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SB
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Series Dual-Axis Precision Slide Cylinder HLQ12X100SB Technical Details
- Model: HLQ12X100SB
- Type: Dual-axis guided slide cylinder with linear guide rail
- Bore size: Ø12mm
- Stroke: 100mm (standard customizable from 20-500mm)
- Max thrust: 130N at 0.63MPa
- Repeat positioning accuracy: ±0.01mm
- Operating pressure: 0.1-0.8MPa
- Temperature range: -20℃ to 80℃
- Main material: Hard anodized aluminum alloy (A6063-T5)
- Seal material: NBR/PU hybrid seals
- Lubrication: Pre-lubricated with Molykote EM-30L grease
- Mounting options: Horizontal/vertical with 4x M4 threaded holes
- Port size: M5x0.8 (standard) with optional G1/8 adapters
- Buffer mechanism: Adjustable rubber cushion (both ends)
- Protection rating: IP54 (standard), IP67 optional
- Weight: 1.25kg ±2%
- Dimensions: 172mm(L) × 34mm(W) × 34mm(H)
High-rigidity dual-axis pneumatic slide featuring crossed roller guides for exceptional moment resistance. The HLQ12X100SB combines 15μm/200mm straightness accuracy with 4.9kN/m radial stiffness, making it ideal for precision alignment tasks. Integrated T-slot design allows direct mounting of sensors or tooling plates. Requires 40μm filtered air with dew point -25℃ below ambient.
- PCB component insertion machines
- Semiconductor wafer handling arms
- Automated optical inspection (AOI) stages
- Medical device assembly stations
- Coordinate measuring machine (CMM) probes
Operational note:
Maintain 0.5-1mm clearance between cylinder body and adjacent components to prevent thermal expansion interference. Lubricate guide rails every 50km of travel using ISO VG32 equivalent grease.
Critical alignment:
Ensure perpendicularity error <0.05mm/100mm between cylinder axis and load center. Use alignment jigs during installation to prevent side load-induced wear.
| Property | Property Value |
|---|---|
| sku | HLQ12X100SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
