Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SBF
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Dual-Axis Precision Slide Cylinder HLQ12X100SBF Specifications
- Model: HLQ12X100SBF
- Type: Dual-axis guided slide cylinder with linear guide rails
- Bore size: Ø12mm
- Stroke: 100mm (standard), customizable up to 500mm
- Max speed: 0.5 m/s (with cushioning)
- Load capacity: 30N radial / 15N lateral
- Repeat positioning accuracy: ±0.01mm
- Operating pressure: 0.1-0.8 MPa
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy (hard anodized surface)
- Seal type: NBR seals with wear-resistant guide bushings
- Mounting style: Horizontal or vertical (dual-axis stabilization)
- Weight: 1.45kg (excluding accessories)
- Dimensions: 300mm(L) × 50mm(W) × 42mm(H) (full extension)
- Cushioning: Adjustable air cushion at both ends
- Lubrication: Pre-lubricated (maintenance-free for 500km travel)
High-precision dual-axis cylinder with integrated linear guides, designed for applications requiring exceptional straightness and minimal deflection. Features cross-roller bearings for smooth motion and anti-corrosion surface treatment. Includes magnetic piston for position sensing compatibility (sensor not included).
- Precision alignment in semiconductor wafer handling
- Optical lens positioning systems
- 3D coordinate measuring machines
- Laser cutting equipment X-Y stages
- Automated micro-dispensing systems
Installation note:
Ensure guide rails are parallel within 0.05mm/m tolerance during mounting. Use M4×0.7 mounting screws (grade 8.8 or higher) with 0.6-0.8Nm torque. Avoid side loads exceeding 10N to maintain accuracy.
| Property | Property Value |
|---|---|
| sku | HLQ12X100SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
