Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SBS
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Series Dual-Axis Precision Slide Cylinder HLQ12X100SBS
- Model: HLQ12X100SBS
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Structure: Dual-axis guided with linear ball bearings
- Material: Aluminum alloy body (anodized), hardened steel shafts
- Operating pressure: 0.1-0.7 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Sensor compatibility: Built-in magnet for proximity sensors (NPN/PNP optional)
- Mounting options: Horizontal/vertical, multiple bracket configurations
- Repeat positioning accuracy: ≤±0.01mm
- Max speed: 0.1-1.5 m/s (lubricated condition)
- Lubrication: Pre-lubricated (maintenance-free design)
- Weight: 1.25kg (excluding accessories)
- Dimensions: 200mm(L) × 42mm(W) × 34mm(H) (full extension)
- Rod end thread: M6×1.0 internal thread (both ends)
- Protection class: IP54 (standard sealing)
High-rigidity dual-axis cylinder with integrated linear guide, designed for precision positioning in automated systems. Features zero-backlash ball bearing guides and dual shock absorbers for smooth operation. The modular design allows integration with servo motors or stepper drivers through optional coupling adapters.
- PCB component insertion machines
- Laser marking equipment positioning stages
- Semiconductor wafer handling systems
- Precision optical alignment devices
- Automated test probe positioning
Installation tip:
Maintain 0.02mm/m alignment tolerance during mounting. Use anti-vibration washers when installing on moving platforms. For high-cycle applications (>1 million cycles), periodic re-lubrication with ISO VG32 hydraulic oil is recommended.
| Property | Property Value |
|---|---|
| sku | HLQ12X100SBS |
| External Stop Block Type | Front Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
