Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X10S
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Dual-Axis Precision Slide Cylinder HLQ12X10S Specifications
- Model: HLQ12X10S
- Type: Dual-axis guided slide cylinder with linear guide rails
- Bore size: Ø12mm
- Stroke: 10mm (standard)
- Repeat positioning accuracy: ±0.01mm
- Max. speed: 500mm/s
- Load capacity:
- Radial: 20N
- Moment: 0.5N·m
- Operating pressure: 0.05-0.8MPa
- Temperature range: -10℃ to 80℃
- Cylinder material: Aluminum alloy (hard anodized)
- Guide rail: High-carbon chromium bearing steel (HRC58-62)
- Seal material: NBR/PU
- Mounting options: Horizontal/Vertical (axial load only)
- Weight: 380g ±5%
- Dimensions:
- Length: 75mm (including stroke)
- Width: 42mm
- Height: 34mm
Ultra-compact dual-axis pneumatic slide featuring integrated linear guides and precision grinding process. The chromium-plated piston rod and preloaded ball bearings ensure minimal backlash (±2μm) and smooth motion. Includes adjustable cushioning and auto-lubrication design for maintenance-free operation. Compatible with vacuum applications when paired with special seals.
- PCB component insertion machines
- Micro-dispensing systems in medical device assembly
- Optical fiber alignment stages
- Semiconductor wafer inspection equipment
- High-speed sorting mechanisms
Installation note:
Requires precise alignment of guide rails (parallelism ≤0.02mm). Use M3x0.5 mounting screws with 0.4-0.6N·m torque. Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation.
| Property | Property Value |
|---|---|
| sku | HLQ12X10S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
