Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X10SA
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Series Dual-Axis Precision Slide Cylinder HLQ12X10SA Specifications
- Model: HLQ12X10SA
- Type: Dual-axis guided slide cylinder with built-in linear guide
- Shaft diameter: 12mm
- Stroke: 10mm (standard), customizable up to 300mm
- Max thrust: 156N (at 0.63MPa)
- Repeat positioning accuracy: ±0.01mm
- Operating pressure: 0.15–0.95 MPa
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, hardened steel guide rods
- Seal type: Special low-friction NBR seals
- Mounting options: Horizontal/vertical, base or flange mounting
- Weight: 0.68kg (excluding accessories)
- Dimensions: 120mm(L) × 42mm(W) × 34mm(H)
- Protection class: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (maintenance-free for 2000km travel)
High-precision dual-axis pneumatic slide cylinder combining cylinder and linear guide functions. Features chromium-plated piston rod with scratch-resistant coating and adjustable cushioning for smooth operation. The integrated guide structure eliminates rotational movement, achieving positioning accuracy equivalent to ISO H7 grade.
- Precision alignment in semiconductor wafer handling
- Linear positioning for medical device assembly
- Automated optical inspection (AOI) equipment
- High-speed pick-and-place systems (up to 5m/s)
- 3D printer/extruder positioning mechanisms
Installation note:
Requires precise parallelism adjustment (±0.05mm/m) between guide rails.
Use torque wrench for mounting bolts (specified 2.0N·m ±10%).
For vertical installations, add 20% safety factor to load calculations.
| Property | Property Value |
|---|---|
| sku | HLQ12X10SA |
| External Stop Block Type | Stroke Adjustment Screws at Both Ends |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
