Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X10SB
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Dual-Axis Precision Slide Cylinder HLQ12X10SB Specifications
- Model: HLQ12X10SB
- Structure: Dual-axis guided structure with linear guides
- Bore size: Ø12mm
- Stroke: 10mm (Standard), customizable up to 500mm
- Accuracy grade: C3 precision class (±0.01mm repeatability)
- Max thrust: 78N (at 0.63MPa)
- Operating pressure: 0.1-0.8MPa
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, hardened steel guide rails
- Seals: NBR/Urethane hybrid seals
- Repeat positioning accuracy: ±0.01mm
- Port size: M5x0.8 (Dual ports for X/Y axes)
- Buffer type: Adjustable rubber cushioning
- Weight: 1.25kg (with standard components)
- Dimensions: 150mm(L) × 60mm(W) × 50mm(H)
- Protection rating: IP54 (Dust protected, splash resistant)
High-rigidity dual-axis pneumatic actuator combining cylinder and linear guide functions. Features preloaded ball bearing guides for zero backlash operation, with chrome-plated piston rod (HRC45 hardness). Includes magnetic sensor slots for position feedback. Requires 5μm filtered air with ISO VG32 lubricant.
- Precision alignment in optical component assembly
- PCB testing equipment positioning stages
- Micro-dispensing systems for adhesives
- Semiconductor wafer handling robots
- Medical device assembly automation
- 3C product component insertion mechanisms
Mounting advice:
Use precision mounting jigs during installation. Maintain perpendicularity within 0.05mm/m.
Apply initial lubrication with MOBILUX EP2 grease on guide rails. Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | HLQ12X10SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
