Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X10SBF
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ12X10SBF Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQ12X10SBF
- Structure: Dual-axis integrated slide mechanism
- Bore size: Ø12mm
- Stroke: 10mm (Customizable: 5-100mm)
- Repeat positioning accuracy: ±0.01mm
- Max thrust: 78N (at 0.63MPa)
- Operating pressure: 0.15-0.95MPa
- Temperature range: -10℃ to 80℃
- Buffer type: Adjustable rubber cushion
- Seal material: Polyurethane (PU) with wear-resistant coating
- Mounting style: Horizontal/Vertical base mounting
- Guide type: Dual linear ball bearings
- Weight: 1.8kg ±5%
- Dimensions: 150mm(L) × 60mm(W) × 42mm(H)
- Rod material: Stainless steel SUS304 with hard chrome plating
- Surface roughness: Ra0.4μm (slide rail)
- Lubrication: Pre-lubricated with Molykote EM-30L grease
High-rigidity dual-axis slide cylinder featuring zero-backlash ball guide mechanism, optimized for micron-level positioning tasks. The anodized aluminum body with precision-ground rails ensures smooth motion characteristics under high moment loads. Integrated mounting slots allow direct connection to servo motors or stepper drive systems.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer inspection systems
- Automated optical measurement devices
- High-speed sorting mechanisms
- Medical device assembly fixtures
Operational guidance:
Maintain 0.5-1mm clearance between adjacent components during installation.
Requires periodic relubrication every 500km of travel using specified grease.
Avoid lateral impact forces exceeding 30N to prevent guide rail deformation.
| Property | Property Value |
|---|---|
| sku | HLQ12X10SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
