Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20S
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ12X20S Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQ12X20S
- Structure: Dual-axis guided slide cylinder with linear bearings
- Bore size: Ø12mm
- Stroke: 20mm (±1mm adjustable)
- Operating pressure: 0.1-0.8 MPa
- Repeat positioning accuracy: ±0.01mm
- Max lateral load capacity: 30N
- Max vertical load capacity: 50N
- Operating temperature: -10℃ to 80℃
- Seal material: Polyurethane (PU) with wear-resistant rings
- Guide type: Precision linear ball bearings
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting: Standard M4 threaded holes (4x on base)
- Weight: 0.85kg (with standard fittings)
- Dimensions: 120mm(L) × 42mm(W) × 36mm(H)
- Rod material: Stainless steel SUS304
- Surface treatment: Black anodized aluminum body
High-precision dual-axis cylinder combining pneumatic actuation with mechanical guidance, featuring ultra-smooth movement (≤0.5N dynamic friction) and zero-backlash operation. The hardened steel guide rails and preloaded ball bearings ensure long-term positional stability under repetitive motion. Includes integrated T-slot for modular tooling attachment.
- Precision alignment stages in semiconductor FOUP handling
- Z-axis lifting mechanisms for laser marking machines
- Micro-positioning in optical fiber alignment systems
- Automated test equipment probe positioning
- 3C industry component assembly fixtures
Installation note:
Maintain parallelism within 0.05mm/m during mounting. Apply lithium-based grease
(ISO VG10 grade) every 50km of travel. Avoid side impact during operation -
use shock absorbers for strokes exceeding 15mm in high-speed applications.
| Property | Property Value |
|---|---|
| sku | HLQ12X20S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
