Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20SA
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ12X20SA Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQ12X20SA
- Type: Dual-axis guided cylinder with linear guide rails
- Bore size: Ø12mm
- Stroke: 20mm (standard), customizable 5-100mm
- Repeat positioning accuracy: ±0.01mm
- Max thrust: 78N (at 0.63MPa)
- Operating pressure: 0.15-0.95 MPa
- Temperature range: -10℃ to 80℃
- Piston rod material: Hard chrome-plated steel (SUS420)
- Guide rail: Precision ground stainless steel (SUS304)
- Seals: NBR/Urethane hybrid seals
- Mounting style: Through-hole base mounting (M4x0.7 threads)
- Weight: 0.68kg (with 20mm stroke)
- Dimensions: 120mm(L) × 42mm(W) × 42mm(H)
- Max speed: 500mm/s
- Cushioning: Adjustable rubber buffers both ends
- Protection rating: IP54 (standard), IP67 optional
High-rigidity dual-axis slide cylinder featuring crossed roller guides for moment load resistance. Incorporates preloaded linear bearings achieving ≤5μm positioning repeatability. Anodized aluminum body with integrated lubrication grooves. Compatible with vacuum environments (option). Requires 5μm filtered air supply.
- PCB laser marking positioning stages
- Micro-dispensing robots in SMT lines
- Optical lens alignment systems
- Precision wafer handling arms
- Medical analyzer probe positioning
- 3D printer Z-axis dual-drive mechanisms
Installation guidelines:
Apply lithium soap-based grease to guide rails monthly.
Maintain ≤0.5mm/m alignment tolerance during mounting.
Use counterbalance valves for vertical installations.
Avoid side loads exceeding 15N·m torque capacity.
| Property | Property Value |
|---|---|
| sku | HLQ12X20SA |
| External Stop Block Type | Stroke Adjustment Screws at Both Ends |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
