Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20SBF
$243.77
Regular price
$251.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQ12X20SBF
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQ Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
Installation note:
Maintain 0.02mm maximum parallel deviation during mounting.
Use torque-controlled tightening (1.2N·m for M4 screws).
Avoid side-load impacts exceeding 30N during operation.
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Series Dual-Axis Precision Slide Cylinder HLQ12X20SBF Specifications
- Model: HLQ12X20SBF
- Structure: Dual-axis guide rod type
- Shaft diameter: 12mm (hardened chromium steel)
- Stroke: 20mm (±0.5mm adjustable)
- Repeat positioning accuracy: ≤±0.01mm
- Max. speed: 500mm/s
- Load capacity: 5N·m (radial), 15N·m (axial)
- Operating pressure: 0.05-0.7MPa
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy (black)
- Seal material: NBR + PU hybrid seals
- Mounting type: Through-hole M4×0.7 (front flange)
- Weight: 1.8kg (with standard fittings)
- Dimensions: 200mm(L) × 42mm(W) × 42mm(H)
- Rod end thread: M6×1.0 internal thread
- Lubrication: Pre-lubricated (Grease-free maintenance)
High-rigidity dual-axis slide cylinder with linear ball bearings and precision ground rods. Features anti-rotation mechanism and dust-resistant design (IP54). Optimized for smooth motion with ≤0.5μm surface roughness on guide shafts. Includes shock absorbers for end cushioning.
Typical Applications:
- Precision alignment in semiconductor wafer handling
- Lens positioning systems for optical equipment
- PCB component press-fitting mechanisms
- Automated inspection probe positioning
- Micro-dispensing systems in medical devices
Installation note:
Maintain 0.02mm maximum parallel deviation during mounting.
Use torque-controlled tightening (1.2N·m for M4 screws).
Avoid side-load impacts exceeding 30N during operation.
Recommended Pairings:
- AirTAC MMLB-15 linear ball bearings
- SRQ-10 compact shock absorbers
- APET-8M magnetic sensors
| Property | Property Value |
|---|---|
| sku | HLQ12X20SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
