Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ20X10-S-AF
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ20X10-S-AF Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQ20X10-S-AF
- Type: Dual-axis guided cylinder with integrated linear guide
- Bore size: 20mm
- Stroke: 10mm (±0.5mm adjustability)
- Operating pressure: 0.1–0.8 MPa
- Max. piston speed: 500mm/s
- Repeat positioning accuracy: ±0.01mm
- Cushioning type: Elastic buffer + adjustable air cushion
- Mounting style: Front flange mounting (ISO 15552 base pattern)
- Guide shaft diameter: 12mm chrome-plated steel
- Rail type: 4-row ball bearing linear guide
- Operating temperature: -10℃ to 80℃
- Material: Aluminum alloy body with hard anodized finish
- Weight: 0.62kg (excluding accessories)
- Dimensions: 110mm(L) × 40mm(W) × 50mm(H) (at mid-stroke)
High-rigidity dual-axis pneumatic actuator combining cylinder and linear guide in one compact unit. Features zero-backlash preloaded bearings and hardened guide shafts for precision multi-directional positioning. Includes built-in T-slot mounting grooves for accessory integration. Requires ISO VG32 hydraulic oil lubrication for guide rails.
- Semiconductor wafer handling robots
- Micro-dispensing systems in PCB assembly
- Precision optical lens alignment stages
- Automated microscope slide positioning
- High-speed pick-and-place with lateral stability
Installation note:
Maintain 0.02mm/m alignment tolerance during mounting. Use torque-limiting wrench
(recommended 1.2N·m) for rail fasteners. Avoid side-load exceeding 15N perpendicular
to axis direction.
| Property | Property Value |
|---|---|
| sku | HLQ20X10-S-AF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
