Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x125-S
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ25x125-S Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQ25x125-S
- Type: Dual-axis guided cylinder with linear guide rails
- Bore size: Ø25mm
- Stroke: 125mm (customizable 50-800mm)
- Max thrust: 1,200N (at 0.7MPa)
- Operating pressure: 0.1-0.9 MPa
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s
- Guide rail type: Square profile with 4-row ball bearing
- Lead: 20mm (ball screw version optional)
- Weight: 3.8kg (standard stroke version)
- Dimensions: 280mm(L) × 62mm(W) × 62mm(H) (at mid-stroke)
- Material: Anodized aluminum body, hardened steel guide rails
- Seals: NBR/Urethane hybrid seals
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (regreasing interval: 1,000km travel)
- Mounting options: Side flange, base mounting, vertical suspension
- Sensor compatibility: Magnetic proximity sensor embeddable
High-rigidity dual-axis actuator combining pneumatic cylinder and precision linear guides, designed for applications requiring exceptional straightness and minimal deflection. Features zero-backlash ball bearing guides and dual piston rod configuration for moment load resistance. Optional encoder-ready versions available for closed-loop control.
- Semiconductor wafer handling robots
- Optical lens alignment systems
- Precision dispensing equipment
- Automated microscope stage positioning
- PCB depaneling machines
- Medical device assembly stations
Installation note:
Requires parallel alignment within 0.05mm/m using precision level during mounting.
Use vibration-damping mounts for high-cycle applications exceeding 5Hz.
For full stroke applications, reduce operating pressure to 0.5MPa maximum.
| Property | Property Value |
|---|---|
| sku | HLQ25x125-S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 125mm |
