Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x150-S
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ25x150-S Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQ25x150-S
- Type: Dual-axis guided slide cylinder with linear guide rails
- Bore size: Ø25mm
- Stroke: 150mm (±0.2mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Max thrust: 490N (at 0.6MPa)
- Dynamic load capacity: 20kg (vertical), 30kg (horizontal)
- Repeat positioning accuracy: ±0.01mm
- Piston rod material: Hardened stainless steel SCM435
- Body material: Aluminum alloy (black anodized)
- Guide rail type: Ball bearing recirculating system
- Lubrication: Pre-lubricated (maintenance-free)
- Buffer type: Adjustable rubber cushioning
- Weight: 2.8kg (with mounting brackets)
- Dimensions: 250mm(L) × 62mm(W) × 42mm(H)
- Operating temperature: -10℃ to 80℃
- Mounting options: Horizontal/vertical, side or base mounting
- ISO standard: 15552 (compatible)
High-precision dual-axis pneumatic actuator combining cylinder and linear guide in one compact unit. Features zero-backlash ball bearing guides and hardened chrome plating for wear resistance. The integrated structure eliminates alignment issues common in modular systems, achieving micron-level repeatability even under side load conditions. Includes built-in magnetic sensor slots (NPN/PNP compatible) for position feedback.
- PCB component insertion machines
- Precision optical alignment systems
- Automated micro-dispensing equipment
- Semiconductor wafer handling
- Laser cutting/engraving positioning
- Medical device assembly lines
Installation note:
Maintain 0.02mm/m alignment tolerance during mounting. Use only with
filtered air (5μm+ oil mist). For vertical applications, reduce
maximum load by 30%. Periodic re-lubrication required after 500km travel.
| Property | Property Value |
|---|---|
| sku | HLQ25x150-S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 150mm |
