Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x50-S
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ Series Dual-Axis Precision Slide Cylinder HLQ25x50-S Specifications
- Model: HLQ25x50-S
- Type: Dual-axis guided slide cylinder with linear guide rails
- Bore size: 25mm
- Stroke: 50mm (±0.5mm tolerance)
- Positioning accuracy: ≤±0.01mm (with preloaded guide)
- Max thrust: 980N (at 0.7MPa)
- Operating pressure: 0.15–1.0 MPa
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal type: NBR + PU hybrid seals
- Repeat positioning accuracy: ±0.005mm
- Max speed: 1.0 m/s (with cushioning)
- Cushioning: Adjustable hydraulic dampers (both ends)
- Mounting style: Horizontal or vertical (dual M5 threaded holes on base)
- Port size: M5x0.8 (dual ports for push/pull operation)
- Weight: 2.8kg (including guide rails)
- Dimensions: 150mm(L) × 80mm(W) × 60mm(H) (stroke extended)
High-rigidity dual-axis cylinder with integrated linear guides, designed for precision linear motion requiring exceptional straightness and minimal deflection. Features preloaded ball bearings for zero backlash and hardened steel shafts (HRC60±2) with chrome plating. Includes wear-resistant scrapers and grease nipples for maintenance. Compatible with vacuum environments when paired with optional seals.
- Precision alignment in semiconductor wafer handling
- Lens positioning systems for optical inspection equipment
- Multi-axis coordinate measuring machines (CMM)
- Automated micro-dispensing systems
- High-speed pick-and-place with <1μm vibration damping
Installation note:
Use precision alignment jigs during mounting (max 0.02mm/m parallelism tolerance). Apply ISO VG32 hydraulic oil for initial lubrication. For vertical installations, add 10-15% extra thrust capacity margin.
| Property | Property Value |
|---|---|
| sku | HLQ25x50-S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <50mm> |
