Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x75-S
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ25x75-S Dual Axis Precision Slide Cylinder Specifications
- Model: HLQ25x75-S
- Type: Dual-axis guided precision cylinder with linear guide rails
- Bore size: 25mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Elastic buffer + external adjustable stopper
- Mounting style: Side mounting holes (M5×0.8, 4 places)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s (with cushioning)
- Temperature range: -10℃ to 80℃ (14℉ to 176℉)
- Material: Aluminum alloy body, hardened steel guide rods
- Seal material: Polyurethane (PU) seals
- Weight: 2.8kg (6.17lbs)
- Dimensions: 175mm(L) × 60mm(W) × 80mm(H)
- Lubrication: Pre-lubricated (Molykote EM-50L grease)
- Protection rating: IP54 (standard), IP67 optional
High-rigidity dual-axis slide cylinder combining pneumatic actuation with precision linear guidance. Features cross-roller recirculating bearings for minimal deflection (<0.03mm at full load). The anodized body resists corrosion in humid environments, while chrome-plated rods prevent particulate shedding. Includes adjustable mechanical stoppers for fine end-position tuning.
- PCB component insertion machines
- Optical lens alignment systems
- Semiconductor wafer handling robots
- Medical device assembly stations
- High-speed sorting mechanisms
- Precision dispensing equipment
Installation guidelines:
Maintain 0.02mm/m alignment tolerance during mounting. Use only
floating joints to prevent side load. For vertical installations,
add counterbalance valves when handling >5kg payloads. Relubricate
every 500km of travel or annually.
| Property | Property Value |
|---|---|
| sku | HLQ25x75-S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 75mm |
