Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SAS
$220.30
Regular price
$227.80
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X10SAS
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation guidelines:
Apply ≤0.5Nm torque during mounting. Use shim plates if mounting surface flatness exceeds 0.1mm/m.
For vertical installations, install air exhaust filters to prevent oil mist accumulation.
Break-in period: Operate at 50% speed for first 500 cycles.
AirTAC HLQL12X10SAS Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X10SAS
- Type: Dual-axis guided rodless cylinder
- Bore size: Ø12mm
- Stroke: 100mm (standard customizable up to 2000mm)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffers both ends
- Repeat positioning accuracy: ±0.01mm
- Guide rod type: Hardened chromium-plated steel with linear bearings
- Seal material: Heat-resistant NBR/PU hybrid seals
- Port size: M5x0.8 (standard) with NPT1/8 adaptor option
- Mounting: Horizontal/Vertical via 4x M4 threaded holes
- Sensor compatibility: Built-in magnet for proximity sensors (SM/SD series)
- Weight: 1.2kg (excluding mounting accessories)
- Dimensions: 200mm(L) × 50mm(W) × 60mm(H) at full extension
- Temperature range: -10℃ to 80℃ (extended to 120℃ with HS seals)
- Lubrication: Pre-lubed (VG32 oil), maintenance-free for 2000km travel
Ultra-precision dual-axis slide cylinder with integrated linear guides, delivering ≤5μm/m straightness. Features anti-rotation stability with ≤0.02° angular deviation under load. Aluminum alloy body with anodized finish resists chemical corrosion. Includes dust-resistant wipers for harsh environments.
Typical Applications:
- High-speed pick-and-place robotic arms (≤2m/s)
- Microdispensing systems in PCB manufacturing
- Optical lens alignment stages
- Semiconductor wafer handling robots
- Precision metrology equipment
Installation guidelines:
Apply ≤0.5Nm torque during mounting. Use shim plates if mounting surface flatness exceeds 0.1mm/m.
For vertical installations, install air exhaust filters to prevent oil mist accumulation.
Break-in period: Operate at 50% speed for first 500 cycles.
| Property | Property Value |
|---|---|
| sku | HLQL12X10SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
