Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SB
AirTAC HLQL12X10SB Dual-Axis Precision Slide Table Cylinder Specifications
- Model: HLQL12X10SB
- Type: Dual-axis precision guided cylinder
- Bore size: 12mm
- Stroke: 10mm (±0.5mm tolerance)
- Axis configuration: Dual linear guide rails
- Operating pressure: 0.05–0.8 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting style: Through-hole base mounting (M4 screw holes)
- Repeat positioning accuracy: ≤±0.01mm
- Max speed: 500mm/s (with cushioning)
- Port size: M5x0.8 (two ports)
- Operating temperature: -10℃ to 80℃
- Body material: Aluminum alloy (hard anodized)
- Seal material: NBR/PU hybrid seals
- Weight: 0.38kg (excluding accessories)
- Dimensions: 150mm(L) × 42mm(W) × 24mm(H)
High-rigidity dual-axis cylinder featuring precision ground guide rails and low-friction seals. The integrated slide table design provides exceptional moment resistance (15N·m lateral torque capacity) while maintaining micron-level positioning repeatability. Includes wear-resistant brass bushings and pre-loaded ball guides for vibration-free operation.
- Semiconductor wafer handling robots
- Optical inspection equipment positioning stages
- Laser marking machine Z-axis adjustment
- Precision dispensing systems
- Micro-assembly fixture controls
Installation note:
Maintain parallelism within 0.05mm between guide rails during mounting.
Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation.
Avoid side loads exceeding 50N during dynamic operation.
| Property | Property Value |
|---|---|
| sku | HLQL12X10SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
