Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X20SB
AirTAC HLQL12X20SB Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X20SB
- Series: HLQL Dual-Axis Type
- Bore size: 12mm
- Stroke: 20mm (customizable 10-300mm)
- Shaft type: Dual chrome-plated guide rods
- Mounting style: Side base mounting (SB)
- Operating pressure: 0.1-0.8 MPa
- Temperature range: -10℃ to 70℃
- Buffer type: Adjustable rubber cushion
- Repeat positioning accuracy: ±0.01mm
- Max lateral load: 6.5N
- Max vertical load: 12N
- Seal material: NBR + polyurethane
- Protection rating: IP54
- Weight: 0.65kg (excluding accessories)
- Dimensions: 75mm(L) × 42mm(W) × 34mm(H)
High-precision dual-axis cylinder with linear ball bearing guides, offering exceptional rigidity and smooth motion. Features anti-rotation mechanism and preloaded guide blocks for minimal deflection. Integrated mounting slots allow direct sensor installation. Requires ISO 8573-1:2010 class 4 compressed air.
- PCB component insertion machines
- Lens polishing equipment positioning
- Semiconductor wafer handling systems
- Precision dispenser XYZ stages
- Medical analyzer probe positioning
Installation note:
Align within 0.05mm parallelism tolerance during mounting. Apply lithium soap-based grease (Molykote EM-30L recommended) to guide rods every 500km of travel. Avoid side impact forces exceeding 20N during operation.
| Property | Property Value |
|---|---|
| sku | HLQL12X20SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
