Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X20SBS
AirTAC HLQL12X20SBS Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X20SBS
- Type: Dual-axis guided rod cylinder with slide mechanism
- Bore size: Ø12mm
- Stroke: 20mm (standard), customizable 5-300mm
- Rod type: Hard chrome-plated steel shafts (dual Ø4mm)
- Operating pressure: 0.05-0.9 MPa
- Port size: M5x0.8 (standard), NPT1/8 optional
- Cushioning: Adjustable rubber buffers (both ends)
- Sensor compatibility: Built-in magnet for proximity switch (Reed/NPN/PNP)
- Seal material: NBR + Special polyurethane compound
- Temperature range: -10℃ to 80℃
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s (with cushioning)
- Mounting: Standard base with 4x M3 threaded holes
- Weight: 0.38kg (with 20mm stroke)
- Dimensions: 105mm(L) × 34mm(W) × 34mm(H)
High-precision dual-axis cylinder featuring ultra-low friction guide rails and preloaded ball bearings, delivering micron-level positioning repeatability. The hardened stainless steel shafts and anti-rotation mechanism ensure stable linear motion under lateral loads up to 2.5N·m. Includes dust-resistant wipers and auto-lubrication design for maintenance-free operation.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer handling robots
- Precision dispensing systems
- Optical inspection device XY tables
Installation note:
Use 0.5Nm torque for mounting screws. For vertical installations,
maintain 0.05-0.15mm clearance between guide shafts and base plate.
Always apply ISO VG32 hydraulic oil during initial setup.
| Property | Property Value |
|---|---|
| sku | HLQL12X20SBS |
| External Stop Block Type | Front Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
