Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SBS
$255.40
Regular price
$262.90
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X30SBS
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Align guide rails within 0.05mm/m parallel tolerance. Use torque wrench for mounting bolts (1.2N·m max).
For vertical installations, add mechanical end lock or brake unit to prevent free fall.
AirTAC HLQL12X30SBS Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X30SBS
- Type: Dual-axis guided rod cylinder (non-rotating piston)
- Bore size: Ø12mm
- Stroke: 30mm (customizable up to 300mm)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable elastic cushion at both ends
- Mounting style: Dual through-hole base mounting
- Repeat positioning accuracy: ±0.01mm
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, chromium-plated piston rod
- Port size: M5x0.8 (standard) with NPT1/8 adaptor option
- Max speed: 500mm/s (with cushion engaged)
- Lubrication: Pre-lubricated (Grease-free operation possible)
- Protection rating: IP54 (standard), IP67 with optional wiper seals
- Weight: 0.8kg (excluding accessories)
- Dimensions: 140mm(L) × 50mm(W) × 42mm(H) (full extension)
High-rigidity dual-axis slide cylinder with integrated linear guide rails, designed for precision linear motion applications. Features hardened steel guide shafts (HRC60+) and zero-backlash ball bushings. Includes magnetic piston for sensor mounting. Optional auto-switch compatibility: D-A93 or D-C73 series.
Typical Applications:
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Medical device assembly with cleanroom requirements
- 3D printer Z-axis dual-drive mechanisms
- Semiconductor wafer inspection systems
Installation note:
Align guide rails within 0.05mm/m parallel tolerance. Use torque wrench for mounting bolts (1.2N·m max).
For vertical installations, add mechanical end lock or brake unit to prevent free fall.
| Property | Property Value |
|---|---|
| sku | HLQL12X30SBS |
| External Stop Block Type | Front Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
