Airtac HRQ Rotary Cylinder HRQ10
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ10 Technical Specifications
- Model: HRQ10
- Type: Compact precision rotary actuator (double-acting)
- Torque output: 0.5 N·m (at 0.63 MPa)
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (standard), G1/8 optional
- Rotation angle: 0–190° adjustable
- Max rotation speed: 150 rpm
- Temperature range: -10℃ to 70℃
- Body material: Anodized aluminum alloy
- Piston seal: NBR with wear-resistant ring
- Weight: 0.42 kg (bare cylinder)
- Dimensions: 56mm(W) × 56mm(H) × 82mm(L)
- Mounting pattern: 30mm × 30mm square flange
- Rotation accuracy: ±0.5° (with cushioning)
- Air consumption: 3.5 L/min (at 0.5 MPa)
- Protection class: IP54 (standard sealing)
High-precision rotary actuator featuring adjustable mechanical stops and built-in cushioning for smooth angular positioning. The compact cube-shaped design integrates mounting grooves for sensor installation, ideal for space-constrained automation systems. Requires 5μm filtered lubricated air (ISO 8573-1).
- Part orientation adjustment in assembly lines
- Valve actuation in semiconductor handling
- 90° flipping mechanisms in packaging machinery
- Precision indexing in CNC fixture systems
- Camera/swivel module rotation in robotics
Installation note:
For optimal performance, maintain alignment within ±0.2mm during mounting.
Use flexible couplings when connecting to driven components. Lubricate pivot
bearings every 2,000km of cumulative rotation.
| Property | Property Value |
|---|---|
| sku | HRQ10 |
| Side Port | M5×0.8 |
| Front Port | M5×0.8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | 10mm |
