Airtac HRQ Rotary Cylinder HRQ100AG
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ100AG Technical Specifications
- Model: HRQ100AG
- Type: Compact rotary actuator (rack and pinion type)
- Bore size: Ø100mm
- Rotation angle: 0-190° adjustable
- Torque output: 35 N·m @ 0.5MPa
- Operating pressure: 0.15-0.8 MPa
- Air port size: 1/4" NPT (G1/4 optional)
- Rotation speed: 0.5-1.5 sec/90° (air pressure dependent)
- Weight: 3.8 kg ±2%
- Dimensions: 165mm(L) × 128mm(W) × 128mm(H)
- Body material: Aluminum alloy with hard anodized surface
- Seal type: NBR + PU combination seals
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Mounting: Standard ISO 15552 mounting pattern
- Protection class: IP54 (standard), IP67 optional
High-torque rotary actuator featuring precision ground gears and dual cushioning adjustment. The HRQ100AG's compact square-body design enables multi-position mounting in confined spaces. Includes auto-lock mechanism for position retention during pressure loss. Requires 5μm filtered compressed air with 10-30% relative humidity.
- 90° part flipping mechanisms in assembly lines
- Index table positioning for CNC loading systems
- Valve actuation in chemical processing equipment
- Solar panel angle adjustment mechanisms
- Automated welding fixture rotation
Installation note:
Maintain 0.5-1mm clearance between mounting surface and cylinder base for thermal expansion.
Use flexible couplings when connecting to heavy loads. Lubricate guide shafts monthly under continuous operation.
| Property | Property Value |
|---|---|
| sku | HRQ100AG |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 100mm |
