Airtac HRQ Rotary Cylinder HRQ2
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ2 Technical Specifications
- Model: HRQ2-○○ (○○ indicates optional rotation angles)
- Rotation angles: 0-90°, 0-180°, 0-190° (customizable)
- Torque range: 0.1-3.0 N·m (adjustable via air pressure)
- Operating pressure: 0.15-0.7 MPa
- Port size: PT1/4 (G1/8 optional)
- Piston diameter: 20mm
- Rotation accuracy: ±1°
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Temperature range: -10℃ to 80℃
- Weight: 2.5 kg (standard configuration)
- Dimensions: 150mm(L) × 80mm(W) × 80mm(H)
- Repeat positioning accuracy: ±0.5°
- Maximum rotation speed: 90°/0.3s (at 0.5MPa)
- Air consumption: 4.5 L/cycle (90° rotation)
Precision rotary actuator with dual adjustable cushioning and magnetic position sensing slots. Features anti-rotation safety pins and grease-free operation. The hardened stainless steel shaft and double-sealed bearings ensure 500km+ service life under continuous operation. Requires ISO 8573-1:2010 Class 3 compressed air.
- 90° part flipping in assembly lines
- Rotary indexing tables for CNC loading
- Valve actuation in process automation
- Camera/lens positioning in optical inspection
- Palletizer arm articulation systems
- Semiconductor wafer handling robots
Mounting advice:
Use M5x0.8 mounting screws with 12N·m torque limit. Maintain 0.5mm
clearance between mechanical stops and rotating parts. Lubricate
every 500,000 cycles with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | HRQ2 |
| Side Port | M5×0.8 |
| Front Port | M5×0.8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | <2> |
