Airtac HRQ Rotary Cylinder HRQ20
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ20 Technical Details
- Model: HRQ20
- Type: Compact rotary actuator (rack and pinion design)
- Bore size: 20mm
- Torque output: 0.5-1.2 Nm (adjustable via air pressure)
- Operating pressure: 0.1-0.7 MPa
- Rotation speed: 100-300 RPM (lubricated condition)
- Rotation angle: 0-190° adjustable
- Port size: G1/8 (BSPP thread)
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.8kg ±5%
- Dimensions: Ø60mm × H80mm (body), shaft Ø12mm
- Mounting pattern: 4×M5 threaded holes (8mm pitch circle)
- Repeat accuracy: ±0.5°
- Air consumption: 5.2L/min @ 0.5MPa
Precision rotary actuator featuring zero-backlash gear mechanism with integrated magnetic sensor slots (M5x0.8 mounting thread). The dual cushioning design allows smooth angular positioning, while the hard chrome-plated shaft resists side load wear. Requires 5μm filtered compressed air with ISO VG32 lubricator oil mist (1:1000 ratio).
- 90° part flipping in assembly lines
- Indexing tables for CNC loading systems
- Valve actuation in process automation
- PCB board positioning in electronics manufacturing
- Camera/lens rotation in optical inspection machines
Installation guidelines:
Mount using vibration-resistant washers. Maintain 0.3-0.5mm clearance between stopper plates.
For vertical mounting, install exhaust mist lubricator downstream. Lubricate shaft weekly with
light machine oil (ISO VG22) through grease nipple.
| Property | Property Value |
|---|---|
| sku | HRQ20 |
| Side Port | M5×0.8 |
| Front Port | M5×0.8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | 20mm |
