Airtac HRQ Rotary Cylinder HRQ200A
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Rotary Cylinder HRQ200A Technical Specifications
- Model: HRQ200A
- Type: Compact rotary actuator (rack and pinion design)
- Rotation angle: 0-190° adjustable (standard), ±5° repeat accuracy
- Bore size: 200mm
- Torque output: 500N·m @ 0.63MPa
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Buffer type: Adjustable cushioning
- Port size: PT1/2 (NPT1/2 optional)
- Material: Aluminum alloy body, hardened steel gear rack
- Weight: 5.8kg (12.8lbs)
- Dimensions: 300mm(L) × 200mm(W) × 200mm(H)
- Rotation speed: 90° in 0.5s @ 0.5MPa
- Lubrication: Pre-lubricated (maintenance-free for 5M cycles)
- Protection rating: IP54 (dust/water resistant)
High-torque rotary actuator designed for heavy-duty angular positioning applications. Features precision ground gears with hardened steel reinforcement for extended service life. Integrated shock absorbers minimize end-position impact, while the double-sealed bearing structure ensures stable rotation even under side loads.
- Automated welding fixture rotation
- Palletizing robot end-effector orientation
- Automotive assembly line part positioning
- Packaging machine turntable drives
- Foundry equipment mold flipping mechanisms
Installation guidelines:
Maintain ≤0.5mm alignment tolerance during mounting. Use flexible couplings for shaft connections.
Lubricate gear teeth with ISO VG32 hydraulic oil every 500,000 cycles. Avoid axial loads exceeding 200N.
- Maximum side load: 150N at cylinder center
- Requires 5μm filtered air with 1-5μm oil mist lubrication
- Allow 15-minute cool-down after continuous 2-hour operation
| Property | Property Value |
|---|---|
| sku | HRQ200A |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 200mm |
