Airtac HRQ Rotary Cylinder HRQ200AG
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ200AG Technical Details
- Model: HRQ200AG (Double-piston gear rack type)
- Rotation torque: 19.6 Nm (without gear) / 34.3 Nm (with gear)
- Operating pressure: 0.1–0.7 MPa
- Rotation angle: 0-190° adjustable (standard 90°±5° preset)
- Port size: PT1/2 (NPT1/2 optional)
- Piston diameter: Ø50 mm
- Material: Aluminum alloy body, chrome-plated piston rod
- Weight: 3.5 kg ±2%
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H)
- Mounting hole spacing: 160mm × 80mm (M6 threaded)
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Rotation speed: 50-300 rpm (pressure-dependent)
- Lubrication: Pre-lubed (Use ISO VG32 turbine oil)
- Protection rating: IP54 (standard)
High-torque rotary actuator with dual piston gear-rack mechanism, engineered for precision angular positioning in heavy-duty automation. Features zero-backlash helical gears and triple sealing system (NBR + PU + dust wiper). Requires filtered air with 5-50μm particles and max 0.1mg/m³ oil content.
- Palletizing robot wrist rotation mechanisms
- CNC machine tool automatic door actuators
- Automotive welding fixture positioners
- Packaging line product orientation systems
- Glass manufacturing mold flipping devices
Installation protocol:
Align mounting surface flatness within 0.1mm/m. Use flexible couplings
for shaft connections to prevent side load. Perform 10-15 dry cycles
before full pressure operation. Lubricate every 5,000km of rotation
or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | HRQ200AG |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 200mm |
